Monopole Tower

The monopole tower is primarily made of rolled steel plates, comprising the tower body and a working platform installed at the top of the tower. The bottom of the tower body has a lower door opening, while the wall of the pipe at the location of the working platform has an upper door opening. Antenna brackets are fixed on the railing of the working platform. Often requiring large-scale machining with high precision requirements, they occupy an area of 9-18 square meters. For monopole tower for sale, choose Junjiang steel tower factory.

Get a Quote

Monopole Telecom Tower Specification


HeightAs per request
ShapePolygonal (6-18 sides)
MaterialQ355B & Q235B or equivalent
Thickness5-30mm
Basic Wind speed180km/h_3 second gust or as per design
Quantity of platformAs per request
Antenna loadAs per request
Antenna TypeGSM, RRU, CDMA, MW etc.
Connection of sectionsOverlap / Flange connection
Dsign standardGB / ANSI / TIA-222-G
Welding StandardAWSD1.1
Surface treatmentHot dip galvanized/Painting
Anti-seismic Grade8
ColorAs per request
Fall Arrest SystemAvailable if need
Nuts and BoltsGr 6.8 and 8.8
Service life30/50 years
CertificationISO9001





Monopole Telecom Tower Features

The monopole lattice telecom tower body includes a climbing ladder made up of a main pole and crossbars, with the main pole firmly connected to the support frame. Support frames are threaded into the connection brackets set on the inner wall of the tower body. Monopole towers have a sleek and straightforward exterior, with a slim and symmetrical design suitable for urban or scenic areas. Due to their compact size, they occupy relatively less ground space. Installation is straightforward with mechanical assistance, and maintenance after installation is not overly challenging.



Monopole Telecom Tower Advantages

1.Our monopole tower can be designed following standards GB/ANSI/TIA-222-G/BS 8100.

2.The connection type of our monopole towers: by outside flange, inside flange or overlap. It’s decided by factual situation and design.

2. All our monopole towers are certified by ISO9001. To meet each client's request, we can do certificates like SGS/TUV/CE/SONCAP/SEC,etc.

3. Surface treatment: hot-dip galvanization standards following GB/T 13912-2002 and ASTM A123, painting or spray. Colors can be tailored.

4. Steel material: mainly GB Q345B,Q355B & Q235B or A36/A572 Gr50/S355JR

5. If client has special requirement of the shape, we can make innovative design.

6. Long working life: each tower can be designed to function 30 or 50 years.

7. Tailored foundation design: to fit in unusual environment like sandy beach, mountain or small-area place.


Monopole Telecom Tower Design

Monopole towers by steel tower manufacturers are quite popular in the telecommunication industry. Monopole towers can be designed to have bigger capacity of antenna loading against big wind resistance. Besides, there are 3 connection types when design among which the overlap and inside flange type can save much container room when shipping so as to save the cost. The third advantage is that the monopoles cover smaller footprint with sleek design. This design makes them more aesthetically pleasing and less intrusive in urban areas. Monopoles also require fewer materials, thus it’s more cost-effective. Also they can be erected more quickly than self-supporting towers, resulting in lower costs and faster installation.


Jun Jiang Monopole Telecom Tower Case

This is a batch of 25m&45m monopole towers which have been sent to Tuvalu. When we made the design, we took the soil condition into account, and designed Stepped foundation. Moreover, due to the high shipping cost, we chose overlap connection over flange connection to save the container room. Its overall surface was hot-dip galvanized according to ASTM A 123 and painted inred and yellow. Besides, we sent an engineer there and guided the installation. All our hard work was approved by the client.
